Inovance MD380T1.5GB User Manual

Description of Function Codes
MD380 User Manual
- 210 -
Function Code Parameter Name Setting Range Default
FA-03 PID action direction
0: Forward action
1: Reverse action
0
 0: Forward action
:KHQWKHIHHGEDFNYDOXHLVVPDOOHUWKDQWKH3,'VHWWLQJWKH$&GULYHVRXWSXW
frequency rises. For example, the winding tension control requires forward PID action.
 1: Reverse action
:KHQWKHIHHGEDFNYDOXHLVVPDOOHUWKDQWKH3,'VHWWLQJWKH$&GULYHVRXWSXW
frequency reduces. For example, the unwinding tension control requires reverse PID
action.
Note that this function is influenced by the DI function 35 "Reverse PID action
direction".
Function Code Parameter Name Setting Range Default
FA-04 PID feedback range 0–65535 1000
7KLVSDUDPHWHULVDQRQGLPHQVLRQDOXQLW,WLVXVHGIRU3,'UHIHUHQFHGLVSOD\8DQG
3,'IHHGEDFNGLVSOD\8
Relative value 100% of PID feedback corresponds to the value of FA-04. If FA-04 is set to
DQG3,'UHIHUHQFHLVWKH3,'UHIHUHQFHGLVSOD\8LV
Function Code Parameter Name Setting Range Default
FA-05 Proportional gain Kp1 0.0–100.0 20.0
FA-06 Integral time Ti1 0.01–10.00s 2.00s
FA-07 Differential time Td1 0.00–10.000 0.000s
 FA-05 (Proportional gain Kp1)
It decides the regulating intensity of the PID regulator. The higher the Kp1 is, the larger
the regulating intensity is. The value 100.0 indicates when the deviation between PID
feedback and PID setting is 100.0%, the adjustment amplitude of the PID regulator on
the output frequency reference is the maximum frequency.
 FA-06 (Integral time Ti1)
It decides the integral regulating intensity. The shorter the integral time is, the larger
WKHUHJXODWLQJLQWHQVLW\LV:KHQWKHGHYLDWLRQEHWZHHQ3,'IHHGEDFNDQG3,'VHWWLQJ
is 100.0%, the integral regulator performs continuous adjustment for the time set in FA-
06. Then the adjustment amplitude reaches the maximum frequency.
 FA-07 (Differential time Td1)
It decides the regulating intensity of the PID regulator on the deviation change. The
longer the differential time is, the larger the regulating intensity is. Differential time is the
time within which the feedback value change reaches 100.0%, and then the adjustment
amplitude reaches the maximum frequency.
