What does user-defined fault 2 mean for Inovance MD380T7.5GB DC Drives?
If your Inovance DC Drive reports a 'User-defined fault 2', it means the user-defined fault 2 signal is being input via DI or virtual I/O. To resolve this, reset the operation.
Why does Inovance DC Drives have overcurrent during acceleration?
When an Inovance DC drive experiences overcurrent during acceleration, it may be due to a grounded or short-circuited output circuit, failure to perform motor auto-tuning, an excessively short acceleration time, an inappropriate manual torque boost or V/F curve, low voltage, starting a rotating motor, a sudden load during acceleration, or an undersized AC drive. To address this, eliminate external faults, perform motor auto-tuning, increase the acceleration time, adjust the manual torque boost or V/F curve, correct the voltage, use rotational speed tracking restart or wait for the motor to stop before starting, remove the added load, or select an AC drive with a higher power class.
What to do if Inovance MD380T7.5GB show overcurrent at constant speed?
If you observe overcurrent at constant speed in Inovance DC Drives, it could be caused by a grounded or short-circuited output circuit, failure to perform motor auto-tuning, low voltage, a sudden load during operation, or an AC drive model with insufficient power. To fix this, eliminate any external faults, perform motor auto-tuning, ensure the voltage is within the normal range, remove any added loads, or choose an AC drive with a higher power class.
Why does Inovance MD380T7.5GB DC Drives have overvoltage during deceleration?
If overvoltage occurs during deceleration in Inovance DC Drives, it could be due to high input voltage, an external force driving the motor, a deceleration time that is too short, or the absence of a braking unit and resistor. To solve this, adjust the voltage to the normal range, eliminate the external force or install a braking resistor, increase the deceleration time, or install the braking unit and braking resistor.
What does accumulative power-on time reached mean for Inovance MD380T7.5GB DC Drives?
If your Inovance DC Drive indicates that the 'Accumulative power-on time reached', it signifies that the preset power-on time has been reached. Clear the record by using the parameter initialization function.
What causes initial position fault in Inovance DC Drives?
If your Inovance DC Drive shows an initial position fault, it means the motor parameters are not set based on the actual situation. Check that the motor parameters are set correctly and verify that the setting of rated current is not too small.
What does AC drive hardware fault mean in Inovance MD380T7.5GB DC Drives?
If your Inovance DC Drive displays an 'AC drive hardware fault', it indicates either an overvoltage or overcurrent condition. Address the issue based on the specific overvoltage or overcurrent troubleshooting steps.
What causes pulse-by-pulse current limit fault in Inovance MD380T7.5GB?
If your Inovance DC Drive is experiencing a pulse-by-pulse current limit fault, it could be due to an excessively heavy load, a locked rotor on the motor, or an AC drive model with insufficient power. To fix this, reduce the load and check the motor and mechanical condition, or select an AC drive of higher power class.
What causes EEPROM read- write fault in Inovance MD380T7.5GB DC Drives?
If your Inovance DC Drive displays an EEPROM read-write fault, it indicates that the EEPROM chip is damaged. Replace the main control board to resolve this.
What causes power input phase loss in Inovance MD380T7.5GB DC Drives?
If your Inovance DC Drives show power input phase loss, it could be due to an abnormal three-phase power input, a faulty drive board, a faulty lightening board, or a faulty main control board. To address this, eliminate external faults or contact Inovance or their agent.
Details safety guidelines and precautions for different usage stages.
Provides general safety advice regarding RCD, leakage current, and motor insulation.
Explains the model designation system and nameplate details.
Describes the physical components of the AC drive units.
Lists the technical specifications of the AC drive.
Details necessary external devices and system configuration.
Describes the function of peripheral electrical devices.
Details the available optional parts for the MD380.
Covers requirements and methods for physical mounting.
Specifies environmental conditions for installation.
Details required spacing for heat dissipation.
Explains different mounting methods for the AC drive.
Covers wiring and connection procedures.
Identifies and describes the main circuit power terminals.
Illustrates connection diagrams for the main power circuit.
Identifies and describes the control circuit terminals.
Illustrates connection diagrams for the control circuit.
Overview of the device's control interface and indicators.
Explains the meaning of status LEDs on the operation panel.
Details the function of each key on the operation panel.
Procedures for accessing and changing parameter settings.
Explains the organization and hierarchy of function codes.
Methods for quickly accessing frequently used function codes.
Explains the function and operation of the MF.K key.
How to monitor the AC drive's current operational status.
Covers basic commands for starting and stopping the motor.
Choosing the method for issuing start/stop commands.
Details different motor startup behaviors.
Explains the different methods for stopping the motor.
Configuration for time-based stopping of the AC drive.
Instructions for low-speed manual operation.
Configuration of speed references and sources.
Using the primary source for setting the running frequency.
Using the secondary source for setting the running frequency.
Utilizing analog inputs as the frequency reference.
Utilizing pulse inputs as the frequency reference.
Implementing PID control for frequency regulation.
Configuration for selecting from multiple preset speeds.
Instructions for changing the motor's rotation direction.
Configuring the drive for fixed length operations.
Utilizing the built-in counting functionality.
Procedures for configuring and tuning motor parameters.
Details essential motor parameters for configuration.
Steps for performing automatic motor parameter optimization.
Managing and switching between different motor parameter sets.
Configuration and application of digital input terminals.
Configuration and application of digital output terminals.
Configuration and application of analog input terminals.
Configuration and application of analog output terminals.
Connection and configuration of encoder (PG) interface.
Setup and usage of serial communication protocols.
Utilizing optional extension cards for expanded functionality.
Configuring user password protection for parameters.
Procedures for backing up and restoring parameters.
Lists all standard function parameters.
Details basic operational parameters.
Lists parameters specific to Motor 1.
Lists parameters for vector control mode.
Lists parameters for V/F control mode.
Configuration settings for digital and analog inputs.
Configuration settings for digital and analog outputs.
Parameters for controlling motor start and stop.
Settings related to the operation panel and display.
Parameters for additional operational features.
Parameters for fault detection and protection functions.
Parameters for configuring the PID controller.
Parameters for swing, length, and counting functions.
Parameters for multi-reference and basic PLC operations.
Parameters for creating custom function code groups.
Parameters for managing user passwords.
Parameters for torque control and limiting.
Configuration for virtual digital inputs and outputs.
Parameters specific to Motor 2.
Parameters specific to Motor 3.
Parameters specific to Motor 4.
Parameters for optimizing drive performance.
Configuration for analog input signal curves.
Settings for user-defined programmable functions.
Settings for direct communication between drives.
Parameters for calibrating analog inputs/outputs.
Detailed explanation of fundamental operating parameters.
Detailed explanation of parameters for Motor 1.
Detailed explanation of parameters for Vector Control mode.
Detailed explanation of parameters for V/F Control mode.
Detailed explanation of Digital and Analog Input terminal functions.
Detailed explanation of Digital and Relay Output terminal functions.
Detailed explanation of motor start and stop operations.
Detailed explanation of operation panel functions and displays.
Detailed explanation of auxiliary operational features.
Detailed explanation of fault codes and protection settings.
Detailed explanation of PID control parameters.
Detailed explanation of swing, length, and counting functions.
Detailed explanation of multi-reference and simple PLC modes.
Explanation of how to configure user-defined parameter groups.
Explanation of password protection settings.
Explanation of torque control and limiting parameters.
Explanation of virtual digital input/output configurations.
Explanation of parameters for Motor 2.
Explanation of parameters for Motor 3.
Explanation of parameters for Motor 4.
Explanation of parameters for performance optimization.
Explanation of analog input curve configuration.
Explanation of user-programmable function settings.
Explanation of point-to-point communication settings.
Explanation of analog signal calibration parameters.
Explanation of AC drive monitoring parameters.
Glossary of electromagnetic compatibility (EMC) terms.
Overview of EMC compliance standards applied to the AC drive.
Details the specific EMC standard EN 61800-3: 2004.
Guidance on selecting necessary external EMC components.
Instructions for installing EMC input filters.
Instructions for installing AC input reactors.
Instructions for installing AC output reactors.
Requirements and specifications for using shielded cables.
Specific criteria for effective shielded cable implementation.
Guidelines for proper cable routing and installation.
Troubleshooting steps for common EMC interference issues.
Key electrical performance data and technical specifications.
Details the physical appearance and dimensions of the AC drive.
Guidance on selecting cable diameters and terminal dimensions.
Recommendations for choosing necessary peripheral electrical devices.
Information on selecting and installing external DC reactors.
Describes how to install the external DC reactor.
Provides physical dimensions for external DC reactors.
Guidance on selecting braking units and resistors.
Details the physical dimensions of braking units.
Guidance on selecting the appropriate power for braking resistors.
Covers regular maintenance procedures for the AC drive.
Details regular checks and cleaning tasks.
Outlines less frequent inspection tasks.
Guidelines for replacing cooling fans and capacitors.
Instructions for proper storage of the AC drive.
Details the terms and conditions of the product warranty.
General guidance for diagnosing and resolving faults.
Specific troubleshooting steps for common fault codes.
General| Model | MD380T7.5GB |
|---|---|
| Power Rating | 7.5 kW |
| Frequency Range | 0-600 Hz |
| Cooling Method | Forced air cooling |
| Storage Temperature | -20°C to +60°C |
| Enclosure Rating | IP20 |
| Output Voltage | 0 to Input Voltage |
| Control Method | V/F control |
| Protection Features | Overcurrent, overvoltage, undervoltage, overload, overheat, short circuit, phase loss |
| Communication Interfaces | RS485, Modbus |
| Relative Humidity | ≤95% RH (non-condensing) |
| Altitude | Up to 1000m (derating above 1000m) |
| Overload Capacity | 150% for 60 seconds |
| Input Voltage | 3-phase 380VAC (-15%) - 440VAC (+10%) |
| Ambient Operating Temperature | -10°C to +40°C |
