To Next PageTo Next PageWhat does user-defined fault 2 mean for Inovance MD380T1.5GB DC Drives?
If your Inovance DC Drive reports a 'User-defined fault 2', it means the user-defined fault 2 signal is being input via DI or virtual I/O. To resolve this, reset the operation.
Why does Inovance DC Drives have overcurrent during acceleration?
When an Inovance DC drive experiences overcurrent during acceleration, it may be due to a grounded or short-circuited output circuit, failure to perform motor auto-tuning, an excessively short acceleration time, an inappropriate manual torque boost or V/F curve, low voltage, starting a rotating motor, a sudden load during acceleration, or an undersized AC drive. To address this, eliminate external faults, perform motor auto-tuning, increase the acceleration time, adjust the manual torque boost or V/F curve, correct the voltage, use rotational speed tracking restart or wait for the motor to stop before starting, remove the added load, or select an AC drive with a higher power class.
What to do if Inovance MD380T1.5GB show overcurrent at constant speed?
If you observe overcurrent at constant speed in Inovance DC Drives, it could be caused by a grounded or short-circuited output circuit, failure to perform motor auto-tuning, low voltage, a sudden load during operation, or an AC drive model with insufficient power. To fix this, eliminate any external faults, perform motor auto-tuning, ensure the voltage is within the normal range, remove any added loads, or choose an AC drive with a higher power class.
Why does Inovance DC Drives have overvoltage during deceleration?
If overvoltage occurs during deceleration in Inovance DC Drives, it could be due to high input voltage, an external force driving the motor, a deceleration time that is too short, or the absence of a braking unit and resistor. To solve this, adjust the voltage to the normal range, eliminate the external force or install a braking resistor, increase the deceleration time, or install the braking unit and braking resistor.
What does accumulative power-on time reached mean for Inovance MD380T1.5GB?
If your Inovance DC Drive indicates that the 'Accumulative power-on time reached', it signifies that the preset power-on time has been reached. Clear the record by using the parameter initialization function.
What causes initial position fault in Inovance MD380T1.5GB?
If your Inovance DC Drive shows an initial position fault, it means the motor parameters are not set based on the actual situation. Check that the motor parameters are set correctly and verify that the setting of rated current is not too small.
What does AC drive hardware fault mean in Inovance DC Drives?
If your Inovance DC Drive displays an 'AC drive hardware fault', it indicates either an overvoltage or overcurrent condition. Address the issue based on the specific overvoltage or overcurrent troubleshooting steps.
What causes pulse-by-pulse current limit fault in Inovance DC Drives?
If your Inovance DC Drive is experiencing a pulse-by-pulse current limit fault, it could be due to an excessively heavy load, a locked rotor on the motor, or an AC drive model with insufficient power. To fix this, reduce the load and check the motor and mechanical condition, or select an AC drive of higher power class.
What causes EEPROM read- write fault in Inovance DC Drives?
If your Inovance DC Drive displays an EEPROM read-write fault, it indicates that the EEPROM chip is damaged. Replace the main control board to resolve this.
What causes power input phase loss in Inovance DC Drives?
If your Inovance DC Drives show power input phase loss, it could be due to an abnormal three-phase power input, a faulty drive board, a faulty lightening board, or a faulty main control board. To address this, eliminate external faults or contact Inovance or their agent.
Detailed safety information graded by danger level (DANGER, WARNING).
Safety precautions to be followed during the wiring process of the AC drive.
Safety measures required before powering on the AC drive.
Safety precautions to be observed after the AC drive is powered on.
Safety guidelines for operating the AC drive.
Safety precautions to be taken during maintenance of the AC drive.
Guidelines for the mechanical installation of the MD380 AC drive.
Methods and processes for mechanical installation, including wall-mounting.
General guidelines for the electrical installation of the AC drive.
Description of the main circuit terminals for single-phase and three-phase AC drives.
Diagrams illustrating the main circuit wiring configurations for various AC drive models.
Description of control circuit terminals, including arrangement and functions.
Diagram and explanation of the MD380's operation panel layout.
Guide on how to view and modify function codes using the three-level menu.
Methods for quickly viewing function codes in base, user-defined, and user-modified modes.
Definition and operation of the MF.K key for function switchover.
Methods for starting and stopping the AC drive, including command sources.
Selection of command sources for starting and stopping the AC drive.
Description of the three startup modes: direct, catching spinning motor, pre-excited.
Description of the two stop modes: decelerate to stop and coast to stop.
Enabling and configuring jog running for temporary low-speed operations.
Methods for setting the main and auxiliary frequency references.
Setting the main frequency source (X) using various input channels.
Using the built-in PID regulator for closed-loop control applications.
Procedures for setting and reversing the motor's rotating direction.
Procedures for setting and auto-tuning motor parameters for optimal performance.
Guidelines for setting motor parameters manually based on the nameplate.
Methods for motor auto-tuning to obtain internal electrical parameters.
Setting and switching between parameter groups for multiple motors.
Description and usage of Digital Input (DI) terminals for various functions.
Description and usage of Digital Output (DO) terminals for various functions.
Description and usage of Analog Input (AI) terminals for various inputs.
Configuration and usage of serial communication protocols like Modbus and CANopen.
Setting and managing the user password for parameter protection.
Procedures for backing up, restoring, and clearing parameters.
Description of basic function codes for the MD380 AC drive.
Using PID control for process applications like temperature and pressure.
Setting the motor's rotating direction (forward/reverse).
Selecting between motor parameter groups for multi-motor applications.
Parameters for configuring Motor 1, including type, power, and voltage.
Parameters for Motor 1 vector control, valid only for vector control mode.
Parameters for V/F control mode, applicable to low load applications.
Description and functions of the MD380's Digital Input (DI) terminals.
Configuring the AC drive's control mode using external terminals (two-wire/three-wire).
Description and functions of the MD380's Digital Output (DO) and analog output terminals.
Parameters for controlling the start and stop operations of the AC drive.
Selecting the startup mode: direct, catching spinning motor, or pre-excited.
Setting startup frequency and its active time for motor torque at startup.
Parameters for DC injection braking and pre-excitation for improved motor response.
Selecting between linear and S-curve acceleration/deceleration modes.
Selecting between decelerate to stop and coast to stop modes.
Parameters related to the operation panel functions and display settings.
Setting the function of the MF.K multifunctional key.
Parameters for auxiliary functions, including jog running and frequency jump.
Setting parameters for jog running frequency, acceleration, and deceleration times.
Setting overcurrent thresholds and delay times for protection.
Configuring the timing function and its duration source.
Parameters for configuring fault detection and protection functions.
Configuring motor overload protection gain and pending coefficient.
Settings for overvoltage stall gain and protective voltage.
Diagram and settings for overcurrent stall protection function.
Configuring input phase loss and contactor close protection.
Configuring output phase loss protection.
Configures action for various faults like power loss and communication faults.
Configures action for faults like overvoltage, motor overheat, and time reached.
Configures action for user-defined faults, load loss, and PID feedback loss.
Selecting action upon instantaneous power failure (no action, decelerate, stop).
Parameters for PID control, including reference, feedback, and action settings.
Selecting the source for the target process PID reference.
Selecting the feedback signal channel for process PID.
Selecting PID parameter switchover condition (DI, deviation, or frequency).
Parameters for wobble function, fixed length control, and counting functions.
Parameters for multi-reference, simple PLC, and PID setting sources.
Parameters for user password, initialization, and display property settings.
Setting and managing the user password for parameter protection.
Procedures for backing up, restoring, and clearing parameters.
Parameters for torque control, including speed/torque selection and digital setting.
Selecting the source for setting torque, including digital and analog inputs.
Parameters for configuring Motor 2, similar to Motor 1 parameters.
Selecting the auto-tuning method (static, dynamic, none).
Setting proportional and integral gains for speed loop PI (Motor 2).
Selecting the control mode (SVC, CLVC, V/F) for Motor 2.
Parameters for optimizing control performance, including PWM and dead zone settings.
Enabling the fast current limit function to reduce overcurrent faults.
Setting the overvoltage threshold for the AC drive.
Parameters for setting AI curves to map input voltage/current to desired output.
Parameters for point-to-point communication using CANlink.
Determining whether the AC drive acts as master or slave in communication.
Parameters for correcting Analog Input/Output (AI/AO) signals.
Electromagnetic compatibility guidelines and standards for the AC drive.
Guidelines for installing EMC input filters to reduce electromagnetic interference.
Requirements for using shielded cables to satisfy EMC standards.
Guidelines for proper cabling practices to minimize electromagnetic interference.
Methods to address current leakage issues and circuit breaker tripping.
Information on selecting the appropriate AC drive model and its dimensions.
Table of electrical specifications and technical data for MD380 models.
Diagrams and dimensions for the physical appearance and mounting of the MD380.
Recommendations for cable diameters and lug models for power terminals.
Guidelines for selecting braking units and resistors based on application needs.
Procedures for maintaining and troubleshooting the MD380 AC drive.
Guidelines for routine maintenance and cleaning of the AC drive.
List of checks to perform during routine maintenance.
Items to inspect periodically, including air ducts, screws, and terminals.
Troubleshooting guide for common faults and their corresponding solutions.
Troubleshooting for inverter unit protection faults (e.g., Err01).
Troubleshooting for overcurrent faults during deceleration and at constant speed.
Troubleshooting for overvoltage faults during acceleration and deceleration.
Troubleshooting for control power supply faults.
Troubleshooting for undervoltage faults.
Troubleshooting for AC drive overload faults.
Troubleshooting for motor overload faults.
Troubleshooting for power input phase loss faults.
Troubleshooting for power output phase loss faults.
Troubleshooting for module overheat faults.
Troubleshooting communication faults.
Troubleshooting for contactor faults.
Troubleshooting for current detection faults.
Troubleshooting for motor auto-tuning faults.
Troubleshooting for encoder faults.
Troubleshooting for EEPROM write faults.
Troubleshooting for AC drive hardware faults.
Troubleshooting for short circuit to ground faults.
Troubleshooting for load lost faults.
Troubleshooting for PID feedback loss during running.
Troubleshooting for pulse-by-pulse current limit faults.
Troubleshooting for motor switchover faults during running.
Troubleshooting for speed feedback error too large faults.
Troubleshooting for motor over-speed faults.
Troubleshooting for motor overheat faults.
Troubleshooting common AC drive symptoms like no display or abnormal operation.
Troubleshooting steps for when the AC drive shows no display at power-on.
Troubleshooting for "HC" display at power-on, possibly due to cable contact issues.
Troubleshooting for "Err23" display at power-on, related to motor or output cable issues.
Troubleshooting for AC drive stopping immediately after running.
Troubleshooting frequent module overheat faults.
Troubleshooting steps when the motor does not rotate after AC drive runs.
Troubleshooting steps when DI terminals are disabled.
Troubleshooting for low motor speed in CLVC mode.
Troubleshooting frequent overcurrent and overvoltage reports.
Troubleshooting Err17 faults related to soft startup contactor issues.
