Inovance MDBUN Series Braking Unit User Manual
Page 15 of 24
4.5 Viewing Status Parameters
When the braking unit is in stop or running state, you can press to display status
parameters in turn.
When the braking unit is in stop or running state, you can view the values of five status
parameters including the bus voltage, output current, present braking rate, and IGBT
module temperature, and fault code. You can press to view the parameter values in
turn, and pay attention to the state of the unit indicators when each parameter value is
displayed.
If the drive is powered off and then powered on, the bus voltage value is displayed by
default.
