Inovance MDBUN Series Braking Unit User Manual
Page 21 of 24
Application
Elevator
Winding and
unwinding
Crane
Centrifuge
Injection
molding
machine
Occasional
braking load
General
application
ED (Braking
Frequency)
20%–30%
20%–30%
50%–60
%
50%–60%
5%–10%
5%
10%
In the following table, the recommended resistance of the braking unit and braking resistor
can meet most drive application requirements (ED from 0% to 100%), and the he braking
resistor power needs to be determined based on different applications. The following table
lists the recommended braking resistor power when ED is 10% and 50%.
Table 7-1 Recommended values of braking unit and braking resistor (Td = 100%)
Rated Power
of Drive
Braking Unit Model
Recommended
Resistance of
Braking Resistor
Recommended
Power of Braking
Resistor
(ED =10%)
Recommended
Power of Braking
Resistor
(ED = 50%)
Three-phase 220 V, braking start voltage = 350 V
18.5 kW
MDBUN-45-S
≥ 8 Ω
≥ 2 kW
≥10 kW
22 kW
MDBUN-45-S
≥ 8 Ω
≥ 2.5 kW
≥12 kW
30 kW
MDBUN-60-S
≥ 6 Ω
≥ 3 kW
≥ 15 kW
37 kW
MDBUN-90-S
≥ 4 Ω
≥ 4 kW
≥ 19 kW
45 kW
MDBUN-90-S
≥ 4 Ω
≥ 5 kW
≥ 23 kW
55 kW
MDBUN-90-S
≥ 4 Ω
≥ 6 kW
≥ 28 kW
75 kW
MDBUN-90-S x 2
≥ 4 Ω x 2
≥ 4 kW x 2
≥ 19 kW x 2
90 kW
MDBUN-90-S x 2
≥ 4 Ω x 2
≥ 5 kW x 2
≥ 23 kW x 2
110 kW
MDBUN-90-S x 3
≥ 4 Ω x 3
≥ 4 kW x 3
≥ 19 kW x 3
132 kW
MDBUN-90-S x 3
≥ 4 Ω x 3
≥ 5 kW x 3
≥ 23 kW x 3
160 kW
MDBUN-90-S x 3
≥ 4 Ω x 3
≥ 6 kW x 3
≥ 28 kW x 3
Three-phase 380 V, braking start voltage = 670 V
37 kW
MDBUN-45-T
≥ 15 Ω
≥ 4 kW
≥ 19 kW
45 kW
MDBUN-45-T
≥ 15 Ω
≥ 5 kW
≥ 23 kW
55 kW
MDBUN-60-T
≥ 11 Ω
≥ 6 kW
≥ 28 kW
75 kW
MDBUN-90-T
≥ 8 Ω
≥ 8 kW
≥ 38 kW
90 kW
MDBUN-90-T
≥ 8 Ω
≥ 9 kW
≥ 46 kW
110 kW
MDBUN-60-T x 2
≥ 11 Ω x 2
≥ 6 kW x 2
≥ 28 kW x 2
132 kW
MDBUN-60-T x 2
≥ 11 Ω x 2
≥ 7 kW x 2
≥ 34 kW x 2
160 kW
MDBUN-90-T x 2
≥ 8 Ω x 2
≥ 9 kW x 2
≥ 40 kW x 2
200 kW
MDBUN-90-T x 2
≥ 8 Ω x 2
≥ 11 kW x 2
≥ 50 kW x 2
220 kW
MDBUN-90-T x 3
≥ 8 Ω x 3
≥ 8 kW x 3
≥ 40 kW x 3
250 kW
MDBUN-90-T x 3
≥ 8 Ω x 3
≥ 9 kW x 3
≥ 43 kW x 3
280 kW
MDBUN-90-T x 3
≥ 8 Ω x 3
≥ 10 kW x 3
≥ 48 kW x 3
Three-phase 480 V, braking start voltage = 760 V
37 kW
MDBUN-45-5T
≥ 17 Ω
≥ 4 kW
≥ 19 kW
45 kW
MDBUN-45-5T
≥ 17 Ω
≥ 5 kW
≥ 23 kW
55 kW
MDBUN-60-5T
≥ 13 Ω
≥ 6 kW
≥ 28 kW
75 kW
MDBUN-60-5T
≥ 13 Ω
≥ 8 kW
≥ 38 kW
90 kW
MDBUN-90-5T
≥ 9 Ω
≥ 9 kW
≥ 46 kW
110 kW
MDBUN-90-5T
≥ 9 Ω
≥ 12 kW
≥ 56 kW
132 kW
MDBUN-60-5T x 2
≥ 13 Ω x 2
≥ 7 kW x 2
≥ 34 kW x 2
160 kW
MDBUN-90-5T x 2
≥ 9 Ω x 2
≥ 9 kW x 2
≥ 40 kW x 2
200 kW
MDBUN-90-5T x 2
≥ 9 Ω x 2
≥ 11 kW x 2
≥ 50 kW x 2
220 kW
MDBUN-90-5T x 2
≥ 9 Ω x 2
≥ 12 kW x 2
≥ 56 kW x 2
250 kW
MDBUN-90-5T x 3
≥ 9 Ω x 3
≥ 9 kW x 3
≥ 43 kW x 3
280 kW
MDBUN-90-5T x 3
≥ 9 Ω x 3
≥ 10 kW x 3
≥ 48 kW x 3
