SMART CHARGE IUoU Chargers
19
10 Trouble Shootings
After connecting and charging the battery, the battery voltage
would not
increase.
If possible, measure with a suitable multimeter during the charging to
verify if the voltage at the battery terminals increases.
Determine whether the terminals are connected properly to the battery
poles. Clean the battery poles if necessary to ensure better connection.
After a charging time of approx. 20 hours, the battery is still
not fully charged
Disconnect the power to the IU0U automatic.
Remove the battery from the charging terminals and wait for a few
minutes.
Then, measure the voltage at the battery terminals with the multimeter.
If the multimeter displays a voltage of 10 V or less, this indicates that the
battery is defective and does not charge any longer.
The battery discharges after a short period of time without
usage.
Measure the voltage at the battery terminals with a suitable multimeter. If
the multimeter indicates a voltage below 12 V of a 12 V battery or a
voltage below 24 V of a 24 V battery, then the battery is too weak to retain
the charge.
SMART CHARGE IUoU Chargers
20
11 Specifications
Model Number:
466095 466094
Battery Connection
Two plus 1A output for
starter battery
One plus 1A output
for starter battery
Input Voltage range
207-253 V AC / 50 – 60Hz
Charging end voltage
14.4V/14.8V
Economic charging voltage
13.8V
Max. battery capacity
300Ah 150Ah
U0 phase limitation
4 h or 8 h
Max. charging current
25A 15A
Operating temperature
0 °C - 50 C°
Dimensions (mm)
240 X 77 x 310 200 x 60 x 260
Fuse: T4 A / 250 V T2A / 250V
Weight:
3.5 kg 2,4kg
Protection
1.Short circuit protection
2.Overload protection
3.Reverse polarity protection
4.Overtemperature protection
The following accessories are available for your IU0U automatic charger:
o Remote control (Model number: 900-RC)
o Temperature sensor (Model number: TF-500)
For any information, please contact your seller.
