SMART CHARGE IUoU Chargers
15
Model No. Supply battery Starter battery
466094
6 to 10mm²
AWG #12 to #10
1 to 2,5mm²
AWG #16 to #14
466095
16 to 25mm²
AWG #10 to #8
1 to 2,5mm²
AWG #16 to #14
230 volts voltage supply
Connect the plug of the 230 volts voltage supply at the unit to a grounded socket
that is secured by an earth leakage circuit breaker.
8 Accessories
8.1 The temperature sensor
The temperature sensor measures the temperature of the battery or the
environment around the battery and transfers the data to the IU0U automatic
charger. With deviating temperatures, the charging voltage increases and
decreases accordingly.
o Lay the cables from the batteries to the IU0U automatic charger.
o Connect the temperature sensor to the back of the IU0U automatic
charger via the socket.
o Attach the sensor head directly to the battery. Use e.g. double-sided
adhesive tape to attach the sensor to the top of the battery or in the
vicinity of the battery (see figure 9).
o Switch the IU0U automatic charger “OFF“ and “ON“ again to activate the
temperature sensor.
8.2 Remote control
The remote control can switch the charger ON and OFF as well as be used for
functional check.
Note
Attach the remote control at a well accessible place to ensure easy access of the
IU0U automatic charger.
SMART CHARGE IUoU Chargers
16
Caution!
Be careful when attaching the remote control, for wiring harnesses,
cables and other components that are in the assembly range could
be damaged in the process!
o Ensure approximately 5,00cm width, 5,50cm height and 2,30cm depth
for the take-up of the remote control.
o Connect the remote control to the IU0U automatic charger. The
connection cable is equipped with two equivalent modular plugs.
o Place the remote control into the opening created. Secure the remote
control with screws on the upper and bottom margin of the faceplate –
use the available drills.
Note
The power switch at the unit must be switched ON, so that the unit can be
switched ON and OFF with the remote control.
9 Using the Charger
9.1 Normal using
With the IUOU automatic charger you can either recharge batteries or supply full
batteries with a conservation charge.
Switch the unit on with the power switch on the rear side of the unit.
9.2 Using the remote control
The power switch at the back of the unit must be switched on “I” so that the
charger can be switched ON and OFF with the remote control.
Press the “ON/OFF” key on the remote control to switch on or off the unit.
9.3 Charging characteristic
The charging characteristic is generally designated as a modified IU0U
Characteristic.
Attention
The maximum battery capacity should not exceed the specified
capacity, otherwise the functions of the individual charging phases
could be influenced.
