INDEX
OUF88 Technical Specifications 2
OUF 88 Installation 3
Troubleshooting and maintenance 4
Wiring Diagram 5
System description and parts 6
Accessories – Leak detection system 7
Leak detection system wiring diagram 8
Installation examples 9
Display quick reference list 10
Display quick reference list
Normal Operation Status:
OUF 88 Oil Lifter is powered. Pump filling No Power Supply
Oil in lifter reservoir arrived till stop level. OUF reservoir
It keeps this state till low level is reached
again, or start button is pushed.
Alarm Status:
Very high level is reached Very low level is reached Leak detection alarm
(if fitted)
No oil Safety Stop: No level probe is detected
Activated after 1 hour
approx. running without oil
Other Status:
x 5…
Reset Sequence Automatic Start Mode facility
Following to an interruption to the power To enter, keep pressing start button during
automatically starts within 3 seconds. 5 green led blinks (5 sec approx) 10
