11
22" 1080p 60Hz LED TV
www.insigniaproducts.com
3 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions that
came with the wall-mount bracket for information about which screws to use and how to correctly hang your TV.
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. We recommend that you use the wall-mount
screws and spacers that came with your TV. They fit most wall-mount
brackets.
• Make sure that the screws you use are the correct length. The threaded
parts of the screws that are inserted into the back of your TV must be at
least 9.5mm in length and not more than 11.5mm in length. If the screws
are too short, your TV may fall off the wall-mount bracket. If the screws
are too long, they may damage components inside your TV. For more
information, see the instructions that came with the wall-mount bracket.
• The mounting holes on the back of your TV take type M4 screws.
3.94 in. (100 mm)
3.94 in. (100 mm)
