Insignia NS-DWR2WH8 Installation Guide

www.insigniaproducts.com
18
Top Control Dishwasher
Method 2
1 Remove the plastic tub caps from the inside of the dishwasher tub.
2 Drive a wood screw through the hole in the side of the dishwasher into the cabinet frame.
3 Reinsert the plastic tub caps.
IMPORTANT:
Drive the screws straight and flush. Protruding screw heads will scratch the side if the dishwasher. This method is for
attaching the dishwasher to the side of the cabinet, and it should be done when the countertop is made of granite or other breakable
materials.
You’ll need:
Plastic
tub cap
Screw
Plastic
tub cap
Phillips screwdriver
Wood screws (2)
(two for each method)
Top mounting clips (2)
NS-DWH2_BS8_SS8_NS-DWR2_BS8_WH8_SS8_17-0939_Install MAN_V5_ENG.fm Page 18 Wednesday, January 24, 2018 2:49 PM

Insignia NS-DWR2WH8 Specifications

General

Brand	Insignia
Model	NS-DWR2WH8
Category	Dishwasher
Language	English
