10
INSTALLATION INSTRUCTIONS
www.insigniaproducts.com
Installing your dryer and washer side-by-side
Leave at least one inch between your appliances and from any surrounding walls. If your washer is a top-loading
washer, make sure that you have enough room to open the washer lid.
24 in.
61 cm
5 in.
12.7 cm
1 in.
2.5 cm
27 in.
68.6 cm
2 in.
5.1 cm
1 in.
2.5 cm
NS-FDRE67WH8A-C_NS-FDRE67WH8A_NS-FDRG67WH8A_17-0815_MAN_V5_EN.fm Page 10 Wednesday, November 15, 2017 12:25 PM
