www.insigniaproducts.com
15
NS-HF2007
STEP 8:
You need:
1 Insert two dowels (EE) into the long edge of the small divider panel (Y).
2 Insert two 4 × 50 mm screws (HH) through the upper shelf (E) and into the small divider panel (Y), then tighten the
screws with a Phillips screwdriver.
E Upper shelf (1)
HH 4 × 50 mm screw
(2)
EE Dowel (2)
Y Small divider
panel (1)
Phillips screwdriver
HH
HH
EE
