Insignia NS-HF2007 User Manual

www.insigniaproducts.com
16
58" TV Gaming Stand
STEP 9:
You need:
Using cam locks
When you insert a cam lock, position the open end of the lock toward the cam screw, then insert the cam screw into the
cam lock opening.
1 Insert the dowels and cam screws on the upper shelf (E) into the dowel cam lock holes on the left and right divider
panels (B and C), then tighten the screws with a Phillips screwdriver.
2 Insert two cam locks (DD) into the left divider panel (B) and two into right divider panel (C) and make sure that the
openings on the cam locks cover the cam screws in the panels.
3 Tighten the cam locks with a Phillips screwdriver.
DD Cam lock (4)
Phillips screwdriver
DD
DD
DD
DD
