Insignia NS-HF2007 User Manual

www.insigniaproducts.com
21
NS-HF2007
STEP 14:
You need:
When you insert a cam lock, position the open end of the lock toward the cam screw, then insert the cam screw into the
cam lock opening.
1 Insert four cam locks (DD) into lower support (H).
2 Insert the cam screws in the base (A) into the cam locks, then tighten the cam locks with a Phillips screwdriver.
DD Cam lock (4)
H Lower support (1)
Phillips screwdriver
DD
DD
DD
DD
