Insignia NS-HTVMF0C User Manual

FIXED-POSITION WALL MOUNT FOR TVs 40-70 in.
7
www.insigniaproducts.com
STEP 3 - Option 1: Attaching the mounting hardware to TVs
with a flat back
1 Align the left and right TV brackets (1) with the upper screw holes on the back of the TV. Make sure that
the brackets are level.
2 Install washers (8) and screws (3, 4, or 5) into the holes in the back of the TV.
3 Install TV standoffs (2) in the lower screw holes on the back of the TV using washers (8) and screws (3, 4,
or 5).
4 Tighten the screws until they are snug against the TV brackets. Do not over tighten.
You’ll ne e d
Important: After attaching
the TV brackets, adjust the
straps (by sliding the buckle
up or down) so they are level
with the bottom of the TV.
2 (2)
3 (4)
Phillips screwdriver
1 TV
brackets (2)
or
4 (4)
8 (4)
5 (4)
Level
or
