15
9.9 and 11.5 cu. ft. Top Mount Refrigerator
www.insigniaproducts.com
11 Attach the center hinge shim to the back of the center hinge, then
align with holes on the left side of the refrigerator and secure it with
the screws you removed from the right side.
12 Place the freezer door on the center hinge. Make sure that the door is
aligned horizontally and vertically, and that the gasket seals on all
sides before attaching the top hinge.
Center hinge shim
Center hinge
NS-RTM10WH7_16-0151_MAN_V3_ENG.fm Page 15 Wednesday, March 30, 2016 2:19 PM
