INSTALLATION INSTRUCTIONS
Installing in a closed cabinet
Minimum clearances between your dryer and adjacent walls or other surfaces are:
• Either side: 1 in. (2.5 cm)
• Rear: 5 in. (12.7 cm)
• Top: 24 in. (61 cm)
• Front: 2 in. (5.1 cm)
1 in.
(2.5 cm)
27 in. (68.6 cm)
1 in.
(2.5 cm)
24.0 in. (61.0 cm)
2.0 in. (5.1 cm)
5 in. (12.7 cm)
30.0 in. (76.3 cm)
