InSinkErator Model SS-75 - Disposer Mounting Assemblies and Dimensions; Bowl Mount Types; Sink Bowl Assembly Sizes; Collar Mount Types

DIMENSIONS
IMPORTANT: Use dimension chart below for adaptor height in place
of InSinkErator bowl sink height when mounting directly to a sink.
Bowl
Sinks
Flange O.D.
X
Work Table Hole
Y
Flange I.D.
Z
Height
12"
(304.8 mm)
13-1/2"
(342.9 mm)
12-1/4"
(311.2 mm)
12"
(304.8 mm)
6-1/2"
(165.1 mm)
15"
(381 mm)
16-1/2"
(419.1 mm)
15-1/4"
(387.4 mm)
15"
(381.0 mm)
6-1/2"
(165.1 mm)
18"
(457.2 mm)
19-1/2"
(495.3 mm)
18-1/4"
(463.6 mm)
18"
(457.2 mm)
6-1/2"
(165.1 mm)
Adaptors X Y Z Height
No. 5
Fits Standard Sink Opening:
3-1/2" – 4" (88.9 mm – 101.6 mm)
2-3/4"
(69.9 mm)
No. 6
7-13/16"
(198.4 mm)
6-7/8"
(174.6 mm)
6-5/8"
(168.3 mm)
1-3/16"
(30.2 mm)
No. 7
9-1/8"
(231.8 mm)
7-7/8"
(200.0 mm)
7-5/8"
(193.7 mm)
2-1/16"
(52.4 mm)
Z
Y
6-5/8"
(168.3 mm)
X
6-13/16"
(173.0 mm)
4-7/8"
(123.8 mm)
6-3/8"
(161.9 mm)
1-1/2"
(38.1 mm)
3-3/8"
(85.7 mm)
6-1/2"
(165.1 mm)
7-11/16"
(195.3 mm)
17"
(431.8 mm)
EXTERNAL ELECTRICAL
CONNECTIONS
1/2-14 N.P.T.
WATER INLET
InSinkErator
BOWL SINK
NOTE:
• Adaptors are available upon request for all competitor
sink bowls or cones.
• Please have sink bowl/cone type with the necessary
dimensions when ordering adaptors.
RECOMMENDED INSTALLATION
DISPOSER MOUNTING ASSEMBLIES (choose one)
Collar Mounts
#6 Collar Adaptor for welding into trough, provides
6-5/8" (168.3 mm) opening, includes splash baffle
#7 Collar Adaptor for welding into sink, provides
6-5/8" (168.3 mm) opening, includes splash baffle
and stopper
#5 Sink Flange Mounting Assemblies for 3-1/2" – 4"
(88.9 mm – 101.6 mm) sink opening (support legs
are recommended)
Bowl Mounts
Type A Sink Bowl Assembly: Includes bowl, water
nozzle(s), bowl cover, splash baffle
Type B Sink Bowl Assembly: Includes bowl, water
nozzle(s), silver guard, splash baffle
Type C Sink Bowl Assembly: Includes bowl, water
nozzle(s), splash baffle
Sink Bowl Assembly Size
12" (304.8 mm) with one adjustable water nozzle
15" (381.0 mm) with one adjustable water nozzle
18" (457.2 mm) with two adjustable water nozzles
Standard Optional
SS-50
3 GPM
(11.4 LPM)
N/A
SS-75
3 GPM
(11.4 LPM)
N/A
SS-100
5 GPM
(18.9 LPM)
3 GPM
(11.4 LPM)
SS-125
5 GPM
(18.9 LPM)
3 GPM
(11.4 LPM)
For additional information, see
Foodservice Product Information Binder.
RECOMMENDED WATER USAGE
