PARTS LIST
Seq. PartNo PartName Spec Q'TY
1 RC801‐630‐001A PowerAdapter 120VAC 1
2 0110‐808‐008 CapNut M8BlackZincPlating 5
3 0116‐008‐010 FlatWasher φ8electrophoretic 26
4 0114‐742‐198 Selftappingscrew ST4.2*19 15
5 RC800‐391‐013 Lockpin φ8*63 1
6 0113‐208‐358A Allenheadbolt M8*35Threadlength:15 2
7 RC801‐260‐002 BackrestAssembly 1
8 RC280‐400‐001 BackrestPad PUfoam 1
9 0113‐208‐708 Allenheadbolt M8*70Threadlength:10 1
10 RC801‐400‐001
SeatBottomPad
Assembly
1
11 RC801‐331‐002 HandlebarR 1
12 RC800‐380‐002 SeatadjustmenthandleR 1
13 B650‐0001‐025 EndCapwithwheel w/Φ30*1.5roundtube
2
14 0114‐129‐138 Selftappingscrew ST2.9*13 2
15 0111‐408‐718 Carriagebolt M8*70halfthread
2
16 RC800‐341‐002 RearStabilizerAssembly
1
17 0116‐608‐008 ArcWasher φ8mm 5
18 0110‐308‐008 CapNut
M8
6
19 RC800‐380‐001 SeatadjustmenthandleL 1
20 RC801‐331‐001 HandlebarL
1
21 RC801‐300‐001 SwingArm
2
22 0111‐008‐208A Hexheadbolt
M8*20
2
23 0116‐208‐508 Enlargedflatwasher M8,BlackZincPlating 2
24 RC801‐310‐001 PedalArmAssemblyR
φ8*δ2mm
1
25 RC800‐200‐000 RearFrameAssembly 1
26 RC801‐630‐001 Console JS1012B(Customized) 1
27 RC801‐310‐002 PedalArmAssemblyL 1
