Inspire FT2 - Step 1: Base Assembly

STEP 1 Base
A) Attach the Rear Cross Brace (3) to the Right and Left Main Bases (1&2) using 4-
M10x120 Hex Bolts (78), 8- M10 washers (97), and 4- M10 Lock Nuts (98).
B) Tighten all the hardware at this time.
Page 6
4 - M10*120 Hex Bolts (78)
8 – M10 Flat Washers (97)
4 – M10 Locknuts (98)
1
2
3
97
98
78
