Inspire FT2 - Step 2: Front Uprights

4L
1
4R
2
STEP 2 Front Uprights
A) Attach the Right Front Upright (4R) to the Right Main Base (1) and the Left Front
Upright (4L) to the Left Main Base (2), using 8- M8x16 Button Head bolts (84)
with 8- M8 washers (100), 2- M10x80 Socket Head Cap Screws (79) with 2-
M10 washers (97) and 2- M10 Lock nuts (98) in the upper hole for the base
flange, 2- M10x90 Hex bolts (80) with 4- M10 washers (97) and 2- M10 Lock
nuts (98) in the lower hole for the base flange.
B) Only finger tighten the hardware at this time. It will be tightened later
in Step 7.
Page 7
2 - M10x80 Socket Head (79)
2 - M10 Flat washer (97)
2 - M10 Locknut (98)
2- M10x90 Hex bolts (80)
4 - M10 Flat washer (97)
2 - M10 locknut (98)
8 - M8*16 Button Head (84)
8 - M8 Flat Washers (100)
