Inspire FT2 User Manual

10
4R
11
12
11
7
8
13
10
4L
9
STEP 5 Weight Bar
A) Place the Right and Left Sliders (8&9) (from step 4) at the same number position
on each Front Upright (4R & 4L).
B) Slide a Shock Absorbing Spring (11) over each Linear Bearing Shaft (10) and rest on the
Slider (8&9) as shown.
C) Place the Right and Left Linear Bearing Sliders (12&13) on the Weight Bar (7) as shown.
Carefully lower the Weight Bar (7) down onto the Linear Bearing Shafts (10) being careful
to not damage the Linear Bearings inside the Sliders (12&13). Continue lowering the
Weight Bar (7) down being careful to keep the bar level or it will bind and damage the
Linear Bearings. Rest the Weight Bar (7) with Linear Bearing Sliders (12&13) on the
Springs (11) on top of each Slider (8&9).
PAGE 10

Inspire FT2 Specifications

General

Type	Functional Trainer
Resistance System	Weight Stack
Frame	Heavy-duty steel
Finish	Powder-coated
Pulley System	High and low pulley stations
Included Accessories	Ankle Strap
Warranty	Lifetime on frame
Material	Steel
