Inspire LEG PRESS 2 OPTION User Manual

PARTS & HARDWARE LIST
Item Parts Description Qty
Qty
Rec'd
Item Hardware Description Qty
Qty
Rec'd
1 Leg Press Base 1 1 Bolt, 3/8-16 x 1" L Button Head 4
2 Press Arm, Left 1 2 Bolt, 3/8-16 x 1" L 2
3 Press Arm, Right 1 3 Bolt, 3/8-16 x 1 1/4" L 2
4 Foot Plate 2 4 Bolt, 3/8-16 x 1 3/4" L 2
5 Leg Press Attachment Arm 1 5 Bolt, 3/8-16 x 2" L 10
6 Back Pad Stem 1 6 Bolt, 3/8-16 x 2 1/2" L 4
7 Dual Pulley Mount 1 7 Bolt, 3/8-16 x 3 3/4" L 1
8 Seat Base 2 8 Bolt, 3/8-16 x 4 1/4" L 2
9 Handle Assy 1 9 Bolt, 3/8-16 x 4 3/4" L 1
10 Floating Dual Pulley Bracket 1 10 Bolt, 3/8-16 x 5" L 5
11 LP2-M4 Attachment Cable 1 11 Bolt, 3/8-16 x 8" L 1
12 Locking Rod 1 12 Bolt, 1/2-13 x 10 3/4" L 1
13 3 1/2" Pulley 9
14 LP2 Main Cable 1 13 3/8" Washer 41
14 3/8" Small OD Washer 6
15 1/2" Washer 2
16 3/8-16 Locknut 18
17 3/8-16 Thin Locknut 4
18 1/2-13 Locknut 1
19 Barrel Spacer, 5/16” Long 1
20 Barrel Spacer, 3/8” Long 4
21 Cable End with Bushing 2
22 Cable Adapter 1
23 Adjustable Bumper 2
24 6mm Allen Wrench 1
Note: There may be extra hardware left over depending on which machine
the LP2 is attached.
