Inspire LEG PRESS 2 OPTION User Manual

Assembly Procedure for Attaching Leg Press 2 to M3
NOTE: The Leg Press may be attached to either side of the Home Gym.
The Illustrations show only one side.
Disconnect Middle Cable
Remove Pulley 1 & 1” Barrel Spacer
from M3 Base Frame
Remove the Swivel Pulley Bracket
from M3 Base Frame
Step 1: Remove the Swivel Pulley Bracket from the M3 Main Upright. Leave the cable
connected to the Swivel Pulley. Save Washers and Locknuts for later use.
Step 2: Remove Pulley 1 and 1” long Barrel Spacer from M3 Main Upright.
Save parts for later use.
Step 3: Disconnect the Middle Cable from the Main Upright. Re-install Bolt, Washers and
Locknut. Wrench tighten bolt.
Page 9
STEP 3
S
TEP 2
STEP
1
Middle Cable
Pulley 1 &
Barrel Spacer
Main Upright
Swivel Pulley
