1 – ¼” Phillips Head Screw
1 – ¼” Flat Washer
1 – 6” Hex Bolt
2 – ½” Flat Washers
1 – ½” Lock Nut
Step 30:
Attach Press Arm to Press Arm Mount using: One (1/2” x 6” Hex Bolt)
Wrench Tighten Now Two (1/2” Flat Washers)
One (1/2” Lock Nut)
Step 31:
Attach Press Arm Plate to Press Arm Mount Using: One (¼” Phillips Screw)
Wrench Tighten Now One (¼” Flat Washer)
Page 20
STEP 31
STEP 30
