Inspire M3 - Initial Frame and Upright Assembly

Main Upright
2 – 3” Hex Bolts
4 – 3/8” Flat Washers
2 – 3/8” Lock Nuts
Rear Base
Step 1: Attach Rear Base to Main Upright using: Two (3/8” x 3” Hex Bolts)
Four (3/8” Flat Washers)
NOTE: Finger Tighten Only Two (3/8” Lock Nuts)
Page 7
STEP 1
