1
6.
After using underwater, remember to shake the camera and allow it time to dry naturally. Do
not use a hair dryer to dry the microphone and speaker holes, as this may damage the internal
waterproof membrane.
7. To keep GO 3 in good, waterproof condition, avoid using GO 3 in high humidity environments
for longer than one hour. This may include saunas, steam rooms or hot springs.
Tips: The suggested working temperature is -4°F-104°F (-20°C-40°C).
8. Do not store in high temperature or humidity environments. Do not store with perfume,
cosmetics or other chemicals that may interfere with the charge points.
9. Do not drop GO 3 or apply strong pressure to the camera, as this will damage it.
10. Do not disassemble GO 3.
1. GO 3 (excluding Action Pod) is waterproof to 5m right out of the box, no other protective
casing is needed. For extended use underwater or to dive deeper, please use the GO 3 dive case
(please refer to the dive case's instructions for details).
2. Before using underwater, ensure the GO 3 Lens Guard is installed. Without this, GO 3 is not
waterproof. Screw on the Lens Guard tightly to prevent any image quality issues.
Note: the Lens Guard comes pre-installed on GO 3.
3. The GO 3 Action Pod is only splashproof (IPX4 water resistant). Do not use the Action Pod in
water.
4. Before use, make sure GO 3's back cover and the Action Pod charging points are both free of
dirt or debris.
Charging Points
Speaker
Microphone
5. After using GO 3 in water (without the Action
Pod), clean and dry it thoroughly with a soft cloth.
Failure to properly dry GO 3 may results in damage
to the camera. Make sure the charging points are
dry and clean before placing it into the Action Pod.
Note: If using in salt water, soak the camera in fresh
water for 15 minutes, then dry.
English

Other manuals for Insta360 GO 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Insta360 GO 3 and is the answer not in the manual?

Insta360 GO 3 Specifications

General IconGeneral
HD type2K Ultra HD
Slow motion4 x
Time lapse modeYes
Video resolutions1920 x 1080, 2560 x 1440 pixels
Maximum frame rate50 fps
Supported video modes1080p, 1440p
Video formats supportedMP4
Maximum video resolution2560 x 1440 pixels
Bitrate at maximum video resolution80 Mbit/s
Sensor type-
Total megapixels- MP
Image formats supportedDNG, INSP
Display diagonal2.2 \
Fixed aperture2.2 mm
Maximum focal length (35mm film equiv)11.24 mm
ISO sensitivity200, 3200
Light exposure correction± 4EV
Audio recording formatsAAC
Storage mediaInternal memory
Frequency band5 GHz
GPS (satellite)No
Wi-Fi standards802.11a, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
USB connector typeUSB Type-C
White balanceAuto
Shutter speed (photo)1/8000 - 120 s
Product colorWhite
Waterproof up to5 m
Protection featuresWaterproof
International Protection (IP) codeIPX8
Battery typeBuilt-in
Charging time1 h
Battery capacity310 mAh
Battery life (max)3 h
Number of batteries supported1
Mobile operating systems supportedAndroid, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16
Operating temperature (T-T)-20 - 40 °C
Warranty period2 year(s)
Weight and Dimensions IconWeight and Dimensions
Depth54.4 mm
Width25.6 mm
Height23.2 mm
Weight35 g
