Technical Information
Model 1000-C 1000-M
Width mm 218 218
Depth mm 465 465
Height mm 440 400
Tap
Clearance
mm 150 150
Power
Rating
KW 3.0 2.25
Rapid
draw-off
Litres 5 3
Weight
(Empty)
KG 8.9 8.4
Weight
(Full)
KG 15.9 14
Water Inlet
Pressure:
Bar 2 to 7 2 to 7 bar
Installation
The boiler must be installed on a horizontal work
surface with sufficient strength to support its weight.
Locate in an area where there is adequate space to
use the boiler safely (e.g. free from risk of congestion
and tripping hazards).
Connection to Mains Water Supply:
Connect the WRAS approved water filling hose
(3/4”BSP) to the inlet connection point on the back
of the boiler and the other end to the mains water
supply, via an accessible isolating tap with a ¾”BSP
thread.
IMPORTANT: If micro-bore pipe is used instead of
the inlet hose supplied, the size must be minimum
OD 3/8”(10mm).
The water supply must have a pressure not
exceeding 7bar (96psi), and no lower than 2bar
(28psi) NOTE: If your water pressure exceeds 7bar,
fit a suitable pressure reduction valve.
We regret that Instanta cannot be held responsible
for any machine malfunctions if the water pressure
exceeds that stated. If in doubt, consult your water
supply company
Electrical Connection:
The boiler must be Earthed.
Your machine is supplied with a standard 13amp
bonded plug with a 13amp fuse.
Overflow:
The drip-tray has a limited capacity and is designed
to handle small spillages and drips. Wherever
possible, we strongly recommend that it is connected
to a permanent waste outlet using the fitting kit
provided.
If preferred, and as an alternative, the overflow can
be connected from the back of the machine using an
optional rear-overflow kit (Pt. No: ROFK1) available
from Instanta Spares Department (01704 502905).
IMPORTANT: Whichever overflow connection is
chosen, the diameter of the pipe used must be no
less than 15mm.
Whilst every reasonable precaution is taken to
prevent an overflow, Instanta cannot be held
responsible for any damage caused as a result
of incorrect installation or blockage of the
overflow or failure to direct the overflow to
a safe outlet.
Operation
First Use (once water and electrical connections
have been made);
• Switch boiler on.
• AMBER LIGHT will illuminate to indicate that the
boiler is filling with water.
• Once primed with water, the RED LIGHT will
illuminate to show that it is heating.
• When the boiler reaches the correct temperature
the GREEN LIGHT will show that the boiler is
ready.
IMPORTANT NOTE: In normal daily use, the boiler
may be used as soon as the GREEN LIGHT shows,
but on first install, wait 15 minutes before starting
to use.
