INSTEON SwitchLinc V2 Dimmer User’s Guide
Mechanical
Paddle Type True rocker action
Paddle and Trim Frame Color White installed, Ivory included;
Optional Almond, Black, Brown, or Gray with #2400xx kits
Wire Nuts 5 included
Mounting Mounts in single or multiple-ganged junction box.
Control 200 W less load for each immediately adjacent SwitchLinc Dimmer
installed. For example, 600 W load control becomes 400 W with another dimmer
to the immediate right or left. Use a triple-gang box with a mechanical switch in
the center to avoid de-rating.
Operating Conditions Indoors, 40 to 104°F, up to 85% relative humidity
Dimensions 4.1” H x 1.8” W x 1.2” D
Weight 3.6 oz
Electrical
Supply Voltage 120 Volts AC +/- 10%, 60 Hertz, single phase
Surge Protection MOV rated for 150 Volts
Power Wire Leads 6”, 16 AWG, stranded,
600V, 105°C insulation, ends stripped and tinned,
LINE (black), LOAD (red), NEUTRAL (white)
Ground Lead 6”, 18 AWG, stranded, bare copper
Load Types Wired-in incandescent lighting devices
Maximum Load 600 Watts (uses 12-Amp triac dimmer)
Minimum Load No minimum load required
Certification Safety tested for use in USA and Canada (ETL #3017581)
