INSTEON SwitchLinc V2 Dimmer User’s Guide
SPECIFICATIONS
SwitchLinc Dimmer Specifications
General
Smarthome Product Number 2476D2, INSTEON SwitchLinc V2 Dimmer Switch
Warranty 2 years
Operation
On-Levels 32
Ramp Rates
(full-ON to full-OFF)
0.125 to 9 seconds if programmed locally,
0.125 seconds to 9 minutes if programmed remotely
LED Bar Brightness Indicator 9 White LEDs,
Optional Green, Blue, Amber, or Red with #2401 kit
Manual Operation Modes INSTEON only, X10 only, INSTEON and X10 Combo Mode
Combo Mode Message Order INSTEON, X10, INSTEON cleanup
Multi-Way Circuit Support One SwitchLinc Dimmer controls load,
Cross-Link any number of SwitchLinc Dimmers or other INSTEON Controllers
Setup Memory Non-volatile EEPROM
INSTEON Features
INSTEON Addresses 1 hard-coded out of 16,777,216 possible
INSTEON Links 417 out of 16,777,216 possible
INSTEON Powerline Frequency 131.65 KHz
INSTEON Minimum Transmit Level 3.2 V
pp
into 5 Ohms
INSTEON Minimum Receive Level 1 mV
pp
nominal
INSTEON Messages Repeated Yes
X10 Features
X10 Primary Address 1 optional (comes unassigned)
X10 Scene Addresses 255 possible
X10 Status Response Supported
X10 Resume Dim Supported (by setting Local On-Level to zero)
X10 Powerline Frequency 120 KHz
X10 Minimum Transmit Level 3.2 V
pp
into 5 Ohms
X10 Minimum Receive Level 10 mV
pp
nominal
X10 Messages Repeated No
Page 33 of 35
