8
STEP 12 Remove the Pathfinder from the adult bike
12A
12B
12C
12A. Flip the quick-release lever up, and unscrew the nut from the other side.
12B. Remove the nut and slide the quick-release bolt completely out.
12C. Slide the coupler assembly out from the seat post clamp. Replace quick-release pin.
STEP 13 Reattach the Pathfinder to the adult bike
13A
13B
13C 13D
13A. Slide the square coupler assembly tube into the seat post clamp.
13B. Align the holes in the coupler assembly and seat post clamp tubes and slide the quick-
release bolt through.
13C. Screw the nut over the threaded end of the pin and tighten with your fingers.
13D. Clamp the quick-release lever all the way down.
STEP 14 Maintenance
14A. Inflate tires with a hand or foot pump to the correct PSI reading shown on the tire.
14B. Lube the chain monthly, or as needed, with bicycle chain oil.
14C. Check all fasteners before each use to make sure they are all secure.
