Chapter: Introduction
1-2 M26-16269-EN
Figure 1-1. The Long Travel Elastomeric Extensometer
Head Assembly
Support Cable
Upper Carriage
Upper Specimen
Clamp Assembly
(see Figure 3-1)
Lower Specimen
Clamp Assembly
(see Figure 3-1)
Lower Carriage
Guide Rod
Base Plate
Reversible Header
Connector
Counterweights
Thumbscrew
Keep Plate
Support Tubes
Headplate
