Instron 2603-080 - Appendix A: General Specifications

A-1
Appendix A
Specifications
• General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
• System Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
• Machine Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
General
2603-080 2603-084 2603-085 2603-086
Full scale travel: 250 mm (10 inch) 750 mm (30. inch)
Extension resolution: 100
m (0.004 inch) 250 m (0.01 inch)
Extension accuracy
(extensometer only):
200 m (0.008 in) or 0.75% of
extension
(whichever is greater)
0.5 mm (0.02 in) or 1% of
extension
(whichever is greater)
Gauge length: Adjustable, 10 to
200 mm
(0.4 to
7.87 inch)
‘Adjustable, 10
to 100 mm
(0.4 to 3.9 inch)
Adjustable, 10 to 100 mm
(0.4 to 3.9 inch)
Gauge length setting: Graduated bar
with marks at
10, 20, 25, 50,
100, 200 mm
and 0.5, 1.0, 2.0,
5.0 inch to allow
setting of gauge
length
Graduated bar
with marks at
10, 20, 25, 50,
100 mm and
0.5, 1.0, 2.0 inch
to allow setting
of gauge length
Graduated bar with marks at 10, 20,
25, 50, 100 mm and 0.5, 1.0,
2.0 inch to allow setting of gauge
length
Gauge length accuracy:
250 m (0.01 inch) at 20C 0.250 mm (0.01 in) at 20C
Maximum specimen width: 20 mm (0.75 inch) 20 mm (0.75 inch)
Maximum specimen thickness: 12.7 mm (0.5 inch) 12.7 mm (0.5 inch)
Specimen gripping force: Adjustable. Nominally 5 to 15 N (500
to 1500 g) for thin specimens, 15 N
(1500 g) for thick specimens
Adjustable. Nominally 5 to 15 N (500
to 1500 g) for thin specimens, 15 N
(1500 g) for thick specimens
Operating force: 0.15 N (15 g) 0.15 N (15 g)
