Installation of the 2603-080 or 2603-085
Installation of the 2603-080 or 2603-085 onto 3300, 4200, 4400, 5500, 5800 and
5900 Series Two Column Machines
The extensometer is mounted on the base platen of the machine. Figure 2-2 shows the
installation.
Figure 2-2. Installation onto 3300, 4200, 4400, 4501/2, 5500, 5800 and 5900 Machines
M10 Screw
M10 Washer
Support Plate
Thick M10 Washer
(4501/2, 6021/2
only)
Shoulder Screw
Spring
Jacking Screw
Base Platen
Extensometer
Base Plate
