Instron 2603-080 - Installation on 4501;4502 Series Two Column Machines

2-5
Unpacking, Handling and Storage
Product Support: www.instron.com
Figure 2-3. Installation onto 4300 Series Machines
M10 Screw
M10 Washer
Support Plate
Pillar
Shoulder Screw
Spring
Jacking Screw
Base Platen
Extensometer
Base Plate
Long Lower Pullrod
Assembly
