A-1
Appendix A
Specification
General
The following specifications are common to
all the Extensometers described in this
manual.
Parameter Value
Linearity 0.15% of Full Scale
Hysteresis 0.15% FS @ 60% Full Scale
Creep
(1)
0.15% of Full Scale
Operating Force (2620-601,-602, -603) 150g
(2620-604) 75g
Output Sensitivity 2.5 mV/V (nominal)
Bridge Resistance 350 Ohms
Balance ±2.5% Full Scale
Excitation 5 Volts Nominal, 10 Volts
maximum AC (RMS) or DC
