InstruStar Electronic Technology http://www.instrustar.com/
ISDS205
3
16 channel: 250K~16M Hz
Sample Points
1M-2GB
Saleae Logic Logic Analyzer (205C/205X)
Channel
8
Sample
25K~24M Hz
Protocol Analyzer
Atmel SWIBiSS CSPII2CCANUART
I2S/PCMDMX-512JTAGLINManchester
1-WIREUNI/OSimple ParallelMDIOUSB1.1
PS/2 Keyboard/Mouse
Sample Points
1MB~10TB
3.Software Installation
Please refer to the "Software and Driver Installation.pdf".
4.Interface
4.1 ISDS205A
DDS(205B/205X)
Wave
Sine, Square(Duty circle variable),Triangle,Up
Sawtooth,Down Sawtooth
Amplitude
≥9Vp-p(no load)
Impedance
200Ω±10%
Offset
±2.5V
Frequency Range
1Hz ~ 20MHz(Sine), 1Hz ~ 2MHz(Others)
Frequency Resolution
1Hz
Frequency Steadiness
±1×10
-3
Frequency Precision
±5×10
-3
Triangular Wave Linearity
≥98% (1Hz~10kHz)
Sine Wave Distortion
≤0.8% (1kHz)
Square Wave Rising/Falling Time
≤100ns
Square Wave Duty Circle
1%~99%
SWEEP
Sweep Range
Fs Fe
Sweep Time Range
0.1 ~10 s
Amplitude
0.5Vp-p ~ 10Vp-p
