Select the speed of data collection.
7.2 Record
Click the lower right corner "data record", the interface
appears in Figure 6.2. Can display the recorded file. Double click
the corresponding file, you can load, view the collected data.
8.Saleae Logic Logic Analyzer
The device to support Saleae Logic software, the development of the hardware above
appropriated Saleae Logic position. Plugged into the USB, the software automatically recognizes
and displays the Connected. Interface shown in Figure 8.1
More information, please view Saleae Logic software instructions, is located in "\Saleae
Logic\Logic Guide.pdf"
Figure 7.2 data record
Figure 8.1 Saleae Logic interface
