InstruStar ISDS205B - Introduction; Feature Description

InstruStar Electronic Technology http://www.instrustar.com/
ISDS205
4
1.Introduction
ISDS205 dual-channel digital oscilloscope, with "low-cost, high-performance"
as the design goals. well-designed bandwidth of 20M, 48M sampling rate, 2 channels,
alternating support X-T and XY alternating pattern of two-channel virtual
oscilloscope, spectrum analyzer, data recorder.
205C and 205X support logic analyzer. Logic analyzer support our Logic
software and Saleae Logic 2 kinds of software, Saleae Logic supports SPI, IIC, UART,
etc. 17 kinds protocol analysis.
205B and 205X support DDS function. DDS support 5 kinds of waveform output,
Sine wave can output up to 20M.
2.Feature Description
Digital Oscilloscope
Channels
2
Impedance
1MΩ 25pF
Coupling
AC/DC
Vertical Resolution
8Bit
Gain Range
-6V ~ 6V（probe X1）
-60V ~ 60V（probe X10）
Vertical Accuracy
±3%
Time Base Range
10ns/div-100ms/div
Input Protection
Diode，50Vpk
Auto Set
Yes(10Hz to 20MHz)
Trigger Mode
Auto、Normal and Signal
Trigger Type
No、Rising edge、Falling edge、
Rising edge or Falling edge
Trigger Level
Yes
Trigger Source
CH1, CH2
Buffer Size
1MB/CH
Bandwidth
20MHz
Max Sample
48MS/s
Oscilloscope
Spectrum Analyzer
Data Recorder
Logic Analyzer
DDS
ISDS205A
√
√
√
ISDS205B
√
√
√
√
ISDS205C
√
√
√
√
ISDS205X
√
√
√
√
√
