InstruStar ISDS205B - Spectrum Analyzers; Data Recorder; Logic Analyzer

InstruStar Electronic Technology http://www.instrustar.com/
ISDS205
2
Vertical Mode
CH1, CH2, ADD, SUB, MUL
Display Mode
X、Y-T 和 X-Y
Measurements
Yes
Wave Save
Osc(Private)、Excel and Bmp
Spectrum Analyzers
Channels
2
Bandwidth
20MHz
Algorithm
FFT(18 windows)、correlation
FFT Points
8-1048576/CHN
FFT Measure
Harmonic(1-7)、SNR、SINAD、ENOB、THD、SFDR
Filter Process
FIR filter supports arbitrary range of frequency
sampling method , and Rectangle, bartlett, triangular,
cosine, hanning, bartlett_hanning, hamming, blackman,
blackman_Harris, tukey, Nuttall, FlatTop, Bohman,
Parzen, Lanczos, kaiser, gaussand dolph_chebyshev,
window method design.
IIR filter support "Butterworth", "Chebyshev I",
"Chebyshev II", "Elliptic" type of filter design
Note: The oscilloscope factory calibration, if you are not satisfied with the
measurements, can manual calibration, the specific reference oscilloscope
instructions.
Data Recorder
Channel
2
Impedance
1MΩ 25pF
Coupling
AC/DC
Vertical Resolution
8Bit
Gain Range
-6V ~ 6V（probe X1）
-60V ~ 60V（probe X10）
Sample
1 channel : 1K~24M Hz
2 channel : 1K~16M Hz
Save File
The maximum 4G, recording time associated with the
sampling rate
Note: The specific speed recorder with computer processing speed, and if use
high sampling rate, the situation may break.
Logic Analyzer(205C/205X)
Channel
16
Sample
8 channel: 250K~24M Hz
