4.4 ISDS205X
5.Oscilloscope / Spectrum analyzer/DDS
Please refer to the "Multi VirAnalyzer User Guide.pdf", "Digital storage oscilloscope
(Professional Version).pdf" and "Digital storage oscilloscope (Simplified Version).pdf".
6.Data Recorder
Please refer to the "Data Recorder.pdf".
7.Logic Analyzer
After the success of USB devices, data recoder, equipment selection drop-downcombo box
will appear ISDS205C/X(1.0) (N) option, choose a good future, the interface in Figure 7.1.
7.1 Basic control
7.1.1 Channel Control
Start or Stop Capture.
7.1.2 Channel Num
Set the num of the channels to be collected.
7.1.3 Sample Length
Set the length of the data to be collected.
7.1.4 Sample
Figure 7.1 properties
