9. BCV SERIES TECHNICAL FEATURES
(1) Cooling capacity under cold room temperature of -20 ºC (-4 ºF) and ambient temperature of 35 ºC (95 ºF).
(2) Total absorbed power by compressor and fans under nominal condition (axial version).
(3) As defined by RD138/2011. IF-01.
(4) Maximum absorbed current even beyond compressor operation limits (axial version).
BCV Series R404A
0018
1018 1026 1034 2034 2054 2074 3074 3086 3096
Cooling capacity
Cooling capacity (1) (W)
479 489 720 866 1048 1349 1633 1930 2270 2460
Absorbed power (2) (W) 620 688 914 1136 1187 1685 2014 2380 2320 2640
COP performance 0,77 0,73 0,79 0,76 0,88 0,80 0,81 0,81 0,98 0,93
Installed power (3) (kW) 0,87 0,88 1,29 1,76 1,76 2,60 3,39 3,39 3,46 4,31
Condenser fan
NF version
Nominal air flow rate (m3/h)
375 575 1000 1350
Type Axial
Power (W) - r.p.m 85W @ 1300 2 x 85W @ 1300 2 x 70W @ 1300
Condenser fan
CF version
Nominal air flow rate (m3/h)
-
575 1000 1350
Available static pressure (Pa)
45 90 120
Type Centrifugal
Power (W) 45 W 105 W 2 x 105 W
Evaporator fan
Nominal air flow rate (m3/h) 300 550 1050 1400
Range (m) 3 4
Type Axial
Power (W) - r.p.m
47W
@
2500
62W @ 2600 2 x 62W @ 2600 2 x 70W @ 2600
Compressor
Type Hermetic reciprocating
Swept volume (m3/h) 3,18 3,18 4,57 6,01 6,01 9,25 12,91 12,91 11,80 16,70
Nominal discharge pressure (bar
rel.)
20
Nominal suction pressure (bar rel.) 1,30
Nominal power (CV) 5/8 5/8 3/4 1 1/4 1 1/4 1 3/4 2 1/2 2 1/2 3 3 1/2
High pressure
switch
Type ACB
Brand Danfoss
Model 061F8175
Cut out (bar rel.) 28
Max. absorbed
intensity (A)(4)
230 V / I ph / 50 Hz 4,8 7,2 8,4 10,9 11,7 17,7 25,7 25,9 No disponible
400 V / III ph / 50 Hz Not available 6,5 7,2 7,4 10,3 12,0
Starting-up
intensity (A)
230 V / I ph / 50 Hz 21,9 21,9 29,9 40,9 41,7 69,7 82,7 82,9 No disponible
400 V / III ph / 50 Hz Not available 24,7 29,7 29,9 26,9 33,9
Refrigerant
Type R-404A / Group L1 / GWP-100: 3922
Load (kg) 0,60 0,70 0,70 0,60 1,15 1,05 1,10 1,50 1,50 1,20
Dimensions
Length (mm) 556 854 854 879
Wide (mm) 420 400 620 735
Height (mm) 683 880 920 920
Weight (kg) 38 59 60 60 89 102 102 131 117 129
Sound pressure level db(A) 33 38 38 40 41 42 43 43 40 50
