4. OPERATION LIMITS
INTARBLOCK and INTARTOP units are designed for continuous operation within the following
temperature limits:
Cold Room Temperature
Ambient Temperature
Max
Min
Max
Min
MCV +10 ºC (50ºF) -5 ºC (23ºF) +45 ºC (113ºF) +15 ºC (59ºF)
BCV -15 ºC (5ºF) -25 ºC (-13ºF) +45 ºC (113ºF) +15 ºC (59ºF)
MCR 10 ºC (50ºF) -5 ºC (23ºF) +45 ºC (113ºF) +15 ºC (59ºF)
BCR -15 ºC (5ºF) -25 ºC (-13ºF) +45 ºC (113ºF) +15 ºC (59ºF)
The unit should work beyond these limits only for short periods of time or during the start-up.
AP
BP
SOLENOID
VALVE
COMPRESSOR
DRAIN BUCKET
EVAPORATOR
CONDENSER
DRAIN TRAYFILTER
AP
BP
PRESSURE
REGULATOR
(only BCV/BCR)
CAPILLARY TUBE /
THERMOSTATIC
EXPANSION VALVE
