intarblock | intartop
13
(1) Cooling capacity under cold room temperature of 0 ºC (32 ºF) and ambient temperature of 35 ºC (95 ºF).
(2) Total absorbed power by compressor and fans under nominal condition (axial version).
(3) As defined by RD138/2011. IF-01.
(4) Maximum absorbed current even beyond compressor operation limits (axial version).
MRC series R134a 0010 0015 1015
2074
Cooling capacity
Cooling capacity (1) (W) 605 788 999 1265 1502 1911 2352
2940
Absorbed power (2) (W) 430 530 580 930 1050 1210 1670
1830
COP performance 1,41 1,48 1,72 1,36 1,43 1,58 1,41 1,61
Installed power (3) (kW) 0,83 0,83 1,22 1,44 1,44 2,2 2,9
Condenser fan
NF version
Nominal air flow rate (m3/h) 375 575 1000
Type Axial
Power (W) - r.p.m 85 W @ 1300 120 W @ 1300
Condenser fan
CF version
Nominal air flow rate (m3/h) 375 575 1000
Available static pressure (Pa) 120
Type Centrifugal
Power (W) 180 W 220 W 2x 200 W
Evaporator fan
Nominal air flow rate (m3/h) 300 600 1150
Range (m) 4
Type Axial
Power (W) - r.p.m
47W @ 2500
62W @ 2600 2x 62W @ 2600
Compressor
Type Hermetic reciprocating
Swept volume (m3/h) 2,08 3,18 3,18 4,51 5,69 5,69 9,26 12,92
Nominal discharge pressure (bar rel.) 10
Nominal suction pressure (bar rel.)
1
Nominal power (CV) 3/8 1/2 1/2 3/4 1 1 1 1/2
2
High pressure switch
Type ACB
Brand Danfoss
Model 061F6147
Cut out (bar rel.) 20
Max. Absorbed intensity(4)(A)
230 V / I ph / 50 Hz 5,94 6,94 7,00 10,70
400 V / III ph /50 Hz Not available
Starting up intensity (A)
230 V / I ph / 50 Hz 16 22 22 29 30 30 46 55
400 V / III ph /50 Hz Not available
Refrigerant
Type R-134a / Grupo A1 / PCA-100: 1430
Load (kg) 0,46 0,50 0,70 0,70 0,60 1,00 1,00 1,10
Dimensions
Length (mm) 790 850 850
Wide (mm) 600 665 835
Height (mm) 330+100 385+135 469+135
Weight (kg) 62 65 73 82 83 98 99 110
Sound pressure level db(A) 30 30 28 34 34 35 39 41
