Intec FORCE/2 - Mechanical Drawings

Fiber Glass
Dam
22141
H
opper
22000
Slide Gate Guide 22000-06 & 22000-07
Agitator 22025
Slide Gate
22000-03
Airlock Seal 22013
Airlock Rotor 22008
without seals
3" Hose
22051
Airlock Bearing
22021
Gearbox
220
1
4/22015
Agitator Motor
21026/21026-S
21027/21027-S
Blower
21024
21025
Base
22004
22004-01
Slide Gate Pin
22000-04
THE FORCE / 2
Mechanical Drawings
MECHANICAL DRAWINGS
29
Airlock Outlet
Plat
e 3" 22005-0
1
Airlock Stainless
Insert 3" 22005-03
Airlock Tube
22005-09
Airlock Inlet Plate
2
1
⁄2" 22005-02
Airlock Stainless
Inser
t 2
1
⁄2" 22005-0
4
