Intec FORCE/2 - Page 32

MECHANICAL DRAWINGS
(Mfg from 8/02-12/06)
1....21000-05-S
ELECTRICAL SYSTEM ASSM.
2....21025-S ..BLOWER, 2 STG, 115V, 60 Hz,
105 CFM, ASSM.
3....21024-S ..BLOWER, 2 STG, 115V, 60 Hz,
116 CFM, ASSM.
4....21026-S ..AGITATOR MOTOR ASSM., 1.5 HP,
115/22OV, 60Hz
4a..21027-S ..AGITATOR MOTOR ASSM., 2 HP,
115/220V, 60 HZ
5....21026-16 AGITATOR MOTOR COVER ABS 1/4"
6
....
2
1
060-0
1 POWER CORD 100' 12/3 COMP,
TWIST LOCK
7....22000 ....HOPPER, STD, BLUE
8....22000-02 HOPPER BELLY BAND, STD
9....22000-03 SLIDE GATE, F/2, STD
10..22000-04 SLIDE GATE CABLE & PIN
1
1
..
22000-06
SLIDE GATE GUIDE, RIGHT
12..22000-07 SLIDE GATE GUIDE, LEFT
13..22004 ....BASE, STD, BLACK
14..22001-01 BASE HOUSING LOUVER 3"
1
5
..
22003-01 BASE PLATE, 1/4" x 28"
16..22014 ....GEARBOX, F/2
1
7
..22015-34 GEARBOX Stabilizer
1
8
..
220
1
5-22
GEARB
O
X SUPPORT PLATE 4" x 4"
19..22023-01 BLOWER COUPLING 8" LONG
20..22025 ....AGITATOR, STD W/SET SCREWS
2
1..22025-01 AGITATOR SNAP RING 1"
22..22025-02 AGITATOR NEOPRENE PAD 1/4"
23
..22025-03 KEY 1/4" x 2-1/2"
2
4
..
22025-05
A
GIT
ATOR MOTOR ROTATION LABEL
25.. 22042-01-S AIRLOCK ASSM. W/BEARINGS
& SS INSERTS
26..22053-02 AGITATOR MOTOR SUPPORT BRACE
27..22131......AIRLOCK GASKET
28..F101........3/8 x 16 x 2-1/4" CAPR. ZN
29..F103 ......3/8 x 16 x 1-1/2" GIRD 2 ELEV. BOLT
30..F104........3/8 x 16 x 1-3" GIRD 5 HEX ZN
31..F107........3/8" SPLIT LOCK WASHER ZN
32..F108 ......3/8" FLAT WASHER SAE
33
..
F1
09
......
3/8 x 16 NYLON LOCK NUT ZN
34..F112 ........1/4 x 20 x 7/8" GIRD 5 HEX ZN
35..F114 ........1/4 x 20 NYLON LOCK NUT ZN
36..F123........#6 x 3/4" SMS PP BLACK
37..F130........3/16 x 11/16" ALUM. RIVET
38..F142........# 8 x 32 x 1/2" PP, TYPE B, SELF TAP.
39..F143........3/8 x 16 x 1" GIRD 5 HEX ZN
40
..F152........1/4 x 20 x 1/2" GIRD 2 ROLOCK
41..F159........1/4" FLAT WASHER SAE
42
..
F1
62........CABLE CLAMP NYLON
43..F223 ......# 10 x 32 x 5/8" PHILL TRUSS ZN
44..F332 ......3/8 x 16 x 2" SOCKET FLAT
C
AP SCREW
45..F333 ......3/8 x 16 x 1-1/2" SOCKET
BUTTON SCREW
46..22050-04 BLOWER CLAMP
47..22026 ....BLOWER REDUCING RING
48..F115 ........1/4" SPLIT LOCK WASHER, ZN
49..F363 ......# 14 FLAT WASHER, ZN
50..F199........M8 SPLIT LOCK WASHER, ZN
51..F198........M8-1.25 x 25 HEX C/S METR. ZN
30
