Integra DHC-80.2B Service Manual

4/157 PAGE
A655 SCREW 3TTB+8B(3CM)SR 2 801637 <B>
A657 SCREW 3TTB+8B(3BC) 3 838430088GR <B>
A659 SCREW 3TTB+8B(3CM)SR 3 801637 <B>
A661 SCREW 3TTB+8B(3CM)SR 1 801637 <B>
A663 SCREW 3TTB+8B(3BC) 3 838430088GR <B>
A671 IB CUSHION W15*3t TAPE 1 28141585 <B>
A681 KNOB (VOL)AS 1 28326231C <B>
A685 CUSHION t0.9*Φ48 1 28141824 <B>
A691 CUSHION (T3*W35*D10) 3 28141741 <B>
A693 CUSHION t5*30*5 1 28141562 <B>
[TRANS COIL]
T903 P TRANS NPT-1581D 1 2301952 <B MDD>
T903 P TRANS NPT-1581M 1 2301953 <B MMA>
T904 P TRANS NPT-1582D 1 2301955 <B MDD>
T904 P TRANS NPT-1582M 1 2301956 <B MMA>
T905 P TRANS NPT-1558D 1 2301911B
N
<B MDD>
T905 P TRANS NPT-1558M 1 2301912B
N
<B MMA>
[SW TRM]
F2001 FUSE 4A-UL/T-233 1 252325GR
!
<B MDD, MMA>
F2001 or FUSE 4A-T/UL-ST2 ( 1) 252257GR
!
<B MDD, MMA>
F2004 FUSE 1.25A-UL/T-233 1 252318GR
!
<B MDD, MMA>
F2004 or FUSE 1.25A-T/UL-ST2 ( 1) 252251GR
!
<B MDD, MMA>
F2005 FUSE 1.25A-UL/T-233 1 252318GR
!
<B MDD, MMA>
F2005 or FUSE 1.25A-T/UL-ST2 ( 1) 252251GR
!
<B MDD, MMA>
F5000 FUSE 3.15A-UL/T-233 1 252323GR
!
<B MDD, MMA>
F5000 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
<B MDD, MMA>
F5001 FUSE 3.15A-UL/T-233 1 252323GR
!
<B MDD, MMA>
F5001 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
<B MDD, MMA>
F9301 FUSE 3.15A-UL/T-233 1 252323GR
!
<B MDD, MMA>
F9301 or FUSE 3.15A-T/UL-ST2 ( 1) 252256GR
!
<B MDD, MMA>
JL4103 JUMPER LEAD JL5 400 H 1 NSP <B>
P106 FFC NCFC7-111012 1 2047111012 <B MDD, MMA>
P3101 SOCKET AS NSAS-10P1813 1 2009991173UL <B>
P4008 FFC NCFC7-090512 1 2047090512 <B>
P4009 FFC NCFC7-150512 1 2047150512 <B>
P4104 FFC NCFC7-311012 1 2047311012 <B MDD, MMA>
P7501 SOCKET AS NSAS-80P1805 1 2009991168UL <B MDD, MMA>
P8002 FFC NCFC5-110512 1 2045110512 <B>
