5/157 PAGE
P8641 FFC NCFCD-31007 1 204D31007 <B>
P9000 AC INLET R301X2PSn 1 25053358
!
<B>
P9008 SOCKET AS NSAS-3P1760 1 2009991127UL
!
<B MMA>
[TUNER UNIT]
U001 BALANCE OUPUT PC BOARD AS BATRM-0237-1A * 1 1B234537-1A
U002 U0020+U0021+U0022 BAAF-0242-1E * 1 1B234542-1E N <B MDD>
U0020 BALANCE INPUT PC BOARD AS BAAF-0242-1E 1 1B2345242-1E
N
<B MDD>
U0021 PRIMARY POWER SUPPLY PC BOARD AS BAPS-0243-1E 1 1B2345243-1E <B MDD>
U0022 INLET PC BOARD AS BAPS-0244-1E 1 1B2345244-1E <B MDD>
U002 U0020+U0021+U0022 BAAF-0242-1F * 1 1B234542-1F N <B MMA>
U0020 BALANCE INPUT PC BOARD AS BAAF-0242-1F 1 1B2345242-1F
N
<B MMA>
U0021 PRIMARY POWER SUPPLY PC BOARD AS BAPS-0243-1F 1 1B2345243-1F <B MMA>
U0022 INLET PC BOARD AS BAPS-0244-1F 1 1B2345244-1F <B MMA>
U0040 U0040+U0041 BAASP-0202-1Q * 1 1B234502-1Q
U0040 AUDIO IN/OUT PC BOARD AS BAASP-0202-1Q 1 1B2345202-1Q
U0041 VIDEO IN/OUT PC BOARD AS BAVD-0203-1Q 1 1B2345203-1Q
N
U005 U0050 ~ U0057 BADG-0208-1N * 1 1B234508-1N <B MDD>
U0050 DAC PC BOARD AS BADG-0208-1N 1 1B2345208-1N <B MDD>
U0051 MICROPROCESSOR PC BOARD AS BACPU-0209-1N 1 1B2345209-1N
N
<B MDD>
U0052 ZONE-2 VOLUME PC BOARD AS BAAR-0210-1N 1 1B2345210-1N
N
<B MDD>
U0053 EQUALIZER AMP PC BOARD AS BAAF-0211-1N 1 1B2345211-1N
N
<B MDD>
U0054 BUFFER AMP PC BOARD AS BAACC-0212-1N 1 1B2345212-1N
N
<B MDD>
U0055 SIRIUS PC BOARD AS BARF-0204-1N 1 1B2345204-1N
N
<B MDD>
U0056 DIGITAL INPUT PC BOARD AS BAETC-0246-1N 1 1B2345246-1N
N
<B MDD>
U0057 D-SUB15 PC BOARD AS BAETC-0247-1N 1 1B2345247-1N <B MDD>
U005 U0050 ~ U0057 BADG-0208-1P * 1 1B234508-1P <B MMA>
U0050 DAC PC BOARD AS BADG-0208-1P 1 1B2345208-1P <B MMA>
U0051 MICROPROCESSOR PC BOARD AS BACPU-0209-1P 1 1B2345209-1P
N
<B MMA>
U0052 ZONE-2 VOLUME PC BOARD AS BAAR-0210-1P 1 1B2345210-1P
N
<B MMA>
U0053 EQUALIZER AMP PC BOARD AS BAAF-0211-1P 1 1B2345211-1P
N
<B MMA>
U0054 BUFFER AMP PC BOARD AS BAACC-0212-1P 1 1B2345212-1P
N
<B MMA>
U0055 SIRIUS PC BOARD AS BARF-0204-1P 1 1B2345204-1P
N
<B MMA>
U0056 DIGITAL INPUT PC BOARD AS BAETC-0246-1P 1 1B2345246-1P
N
<B MMA>
U0057 D-SUB15 PC BOARD AS BAETC-0247-1P 1 1B2345247-1P <B MMA>
U006 U0060 ~ U0067 BADIS-0121-1C * 1 1B234521-1C
U0060 DISPLAY PC BOARD AS BADIS-0121-1C 1 1B2345121-1C
U0061 LED-SW PC BOARD AS BASW-0122-1C 1 1B2345122-1C
U0062 PHONE JACK PC BOARD AS BAETC-0123-1C 1 1B2345123-1C
