Integra DHC-80.2B Service Manual

6/157 PAGE
U0063 FRONT OPT IN PC BOARD AS BAETC-0124-1C 1 1B2345124-1C
U0064 VOLUME PC BOARD AS BAETC-0125-1C 1 1B2345125-1C
U0065 POWER SUPPLY (SEC) PC BOARD AS BAPS-0126-1C 1 1B2345126-1C
U0066 HOLDER(U0063) PC BOARD AS BAETC-0127-1C 1 1B2345127-1C
U0067 HOLDER(U0101) PC BOARD AS BAETC-0128-1C 1 1B2345128-1C
U008 HDMI PC BOARD AS BAHDM-0157-1G * 1 1B234557-1G
U0091 FRONT HDMI/USB PC BOARD AS BAHDM-0291-1B 1 1B2345291-1B
U011 TUNER UNIT FAEH06-E01EX 1 240165 <B MMA>
U011 TUNER UNIT FAEH06-A01US 1 240166 <B MDD>
DHC-80.2
PACKING PROCEDURES PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[PACKING]
A711 SHEET T0.515*1300*900 1 29096066 <B>
A713 SHEET T0.5x600x500 1 29096097 <B>
A719 TAPE (SEROHAN)NITTO NO.29 1 29110149 <B>
A731 CARTON DHC80.2DD 1 29055160
N
<B MDD, MMA>
A733 PAD (AS) 1 29092475C <B>
A737 SHEET (ACC) 1 29096104 <B>
A739 STAPLE FUKAN-BARI(1000KO) 4 282321 <B>
A741 PP TAPE W50 SBT-70 1 29110200 <B>
A751A UPC LABEL DHC80.2MDD { 1} 29391272
N
<B MDD>
A751A EAN LABEL DHC80.2(B)MMA { 1} 29391283
N
<B MMA>
A761 LABEL (MMA) 2 29390973 <B MMA>
[ACCESSARY]
A341 LABEL (PT)INTEGRA 1 29391420
N
<B>
A819 INS MANUAL En(DHC-80.2) 1 29400447
N
<B MDD, MMA>
A853 INS MANUAL En(InternetRadio_INT) 1 29400368 <B MDD>
A871 INS MANUAL U9(2010_Prepro) 1 29400269 <B MDD, MMA>
A873 INS MANUAL U2JaEn(SW_Lice_708-5008) 1 29400366 <B MDD, MMA>
A891 INST SHEET U11(2010_RIHD) 1 29355782 <B MDD, MMA>
A893 INST SHEET U11(2010M/H_A.P.D.) 1 29355790 <B MDD, MMA>
A901 INST SHEET WEEE 1 29355793 <B MMA>
A921 HANDBILL (UP-A1)US 1 29380155A <B MDD>
A931 HANDBILL (SIRIUS) 1 29380149 <B MDD>
