1/8PAGE
DPS-6.5
EXPLODED VIEW PARTS LIS
<Notes>
! :Safety parts
<MDD> :North American area
<MUA> :Australia area
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EXP
A001 CHASSIS DV-SP402E 1 27100447
EXP
A003 LEG LEG 4 27175316C
EXP
A005 CUSHION --- 8 28141494
EXP
A007 SCREW 3TTB+8B 29 838130088
EXP
A008 IB CUSHION W15x3t TAPE 1 28141585 MP0082:CM
EXP
A009 TAPE TAPE(CLOTH-16U) ( 1) 29110083 MP0080.18:MT
EXP
A010 BRACKET (DG) 1 27130963A DG PWB
EXP
A012 HOLDER KGLS-24RT 3 27190814 PWB-CHASSIS
EXP
A013 BRACKET (POW) 1 27130962A POW PWB
EXP
A015 SCREW 4TTC+6C(BC) 2 830440069
EXP
A018 TAPE TAPE(CLOTH-8U) ( 1) 29110082 :0.12:MT
EXP
A020 LABEL(DVD2) --- 1 29362648
EXP
A025 F BRACKET (B) 1 27111325A
EXP
A026 KNOB (STANDBY) 1 28325756
EXP
A027 CLEAR PLT --- 1 28191993
EXP
A028 B PLATE DPS-5.4(B) 1 28133410
EXP
A029 TAPE --- ( 2) 29110161 FBRACKET
EXP
A033 SCREW 2.6TTB+8B(BC) 3 838426088
EXP
A034 CUSHION --- 2 28141606 F BRACKET
EXP
A040 KNOB (CRS) 1 28326078
EXP
A051 DOOR --- 1 28148479A
EXP
A052 PLATE (DVD) 1 27262744 N
EXP
A055 COVER (B) 1 28184864
EXP
A056 SCREW 3TTB+8B(BC) 24 838430088
EXP
A401 F PANEL DPS6.5(B) 1 27212706 N
EXP
A403 BADGE --- 1 28135278
EXP
A404 FACET (S) 2 28198906
EXP
A411 REAR PANEL DPS6.5MDD1N 1 27123348A <MDD> N
EXP
A411 REAR PANEL DPS6.5MUA4P 1 27123349A <MUA> N
EXP
A414 SCREW 4TTB+8C(BC) 2 838440089
EXP
A415 TAPE TAPE(CLOTH-8U) ( 1) 29110082 RAR PANEL:0.09:MT
EXP
CN1 PLUG NPLG-2P632 1 25055676 NGPS-0048
EXP
CN103 SOCKET AS NSAS-10P1135 1 20044391030
EXP
CN201 FFC NCFC5-152022 1 2045152022
EXP
CN451 FFC NCFC6-170522 1 2046170522
EXP
F1 FUSE 1.6A-TL/T-ST2 1 252252
! <MDD>
EXP
F1 FUSE 2.5A-TH250V 1 252310
! <MUA>
EXP
F2 FUSE LABEL F1 1.6A125V 1 29364012
<MDD>
EXP
CP1 Protector 491.800PAR (0.8A) 252311
EXP
P901A CORE NFY-25 BLACK 1 230945
EXP
P910 WIRE TIE BSK-1 4 260208
EXP
S731 JOY STICK NPS-115-S673 1 25035710
EXP
U01 Front display PC board AS NADIS-8416-1G 1 1H524516-1G <MDD> N
EXP
U01 Front display PC board AS NADIS-8416-1H 1 1H524516-1H <MUA> N
EXP
U02 Standby LED PC board AS NADIS-8417-1G 1 1H524517-1G <MDD> N
EXP
U02 Standby LED PC board AS NADIS-8417-1H 1 1H524517-1H <MUA> N
EXP
U03 Audio/ Video output PC board AS NAAR-8419-1G 1 1H524519-1G <MDD> N
EXP
U03 Audio/ Video output PC board AS NAAR-8419-1H 1 1H524519-1H <MUA> N
EXP
U04 Inlet terminal PC board AS NAPS-8420-1G 1 1H524520-1G <MDD> N
EXP
U04 Inlet terminal PC board AS NAPS-8420-1H 1 1H524520-1H <MUA> N
EXP
U05 DVD Main board AS DB-VPB613 1 24150062 N
EXP
U06 Power supply unit NGPS-0047 (100-120V) 1 24150047
<MDD>
EXP
U06 Power supply unit NGPS-0048 (100-240V) 1 24150048
<MUA>
EXP
Z101 DVD Mechanism DB-VLD601 1 24801024
EXP
Z102 HOLDER (ML) 1 27191201
EXP
Z103 HOLDER (MR) 1 27191202
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
